RTZ1-50/0.4(0.8)E(K)Q Gas Pressure Regulator - Hebei Ouyinuo|High Accuracy, Safety Features

The RTZ1-50/0.4(0.8)E(K)Q Series Gas Pressure Regulator is a cutting-edge solution designed for precise and stable pressure regulation in various gas distribution systems. Developed by **Hebei Ouyinuo Gas Equipment Co., Ltd.**, this regulator combines advanced engineering with robust safety features to meet the demands of modern gas infrastructure. This article provides a comprehensive overview of the product's features, technical specifications, applications, and the company's expertise in gas equipment manufacturing.

Key Features of the RTZ1-50/0.4(0.8)E(K)Q Series

The RTZ1-50/0.4(0.8)E(K)Q Series is engineered to deliver exceptional performance in gas pressure regulation. Its key features include:

• High Pressure Regulation Accuracy: The regulator ensures precise pressure control, maintaining stability even under fluctuating input conditions.
• Large Flow Capacity: Designed to handle high gas flow rates, making it suitable for industrial and commercial applications.
• Built-in Safety Mechanisms: Equipped with an overpressure safety cut-off and a safety relief device, eliminating the need for additional safety valves.
• Quick Response Time: The safety cut-off and relief mechanisms operate with high accuracy and rapid response to prevent system failures.
• Easy Maintenance: The simple structure allows for online maintenance, reducing downtime and operational costs.
• Flexible Assembly Options: Can be integrated into box-type, cabinet-type, or station-type pressure regulating equipment, offering customization for different installation scenarios.

Read More About regulating valve

Technical Specifications and Performance

The RTZ1-50/0.4(0.8)E(K)Q Series is designed to meet rigorous industry standards. Below is a detailed breakdown of its technical parameters:

Parameter	Specification
Inlet Pressure (P1)	0.02–0.4 (0.8) MPa
Outlet Pressure (P2)	1–30 KPa, 30–150 KPa
Pressure Regulation Accuracy Grade	Up to AC2.5
Closing Pressure Grade	Up to SG5
Cutting Accuracy Grade	Up to AC5
Operating Temperature Range	-20°C to +60°C
Pass-Through Diameter (DN)	DN50
Connection Mode	Flange connection (PN1.6 MPa, HG/T20592-2009)

The regulator's performance is further validated by its compliance with GB 27790–2020, the Chinese national standard for city gas pressure regulators. This ensures that the product meets the highest quality and safety requirements for gas distribution systems.

Pressure Regulation Performance Table

The following table illustrates the regulator's performance under different inlet pressure conditions:

Inlet Pressure (MPa)	Export Pressure (KPa)	3	10	20	30	50	100	150
0.05	160	230	210	200
0.10	200	450	430	430	210
0.15	250	600	580	520	280	220
0.20	300	750	720	680	570	490	420
0.30	400	980	950	900	840	780	730
0.40	500	1120	1080	1050	960	900	820

Read More About electric regulating valve

Applications and Industry Use Cases

The RTZ1-50/0.4(0.8)E(K)Q Series is designed for a wide range of applications, including:

• Natural Gas Distribution: Ensures stable pressure regulation in municipal and industrial gas networks.
• Coal Gas and Liquefied Petroleum Gas (LPG) Systems: Provides reliable pressure control for non-corrosive, pre-filtered gases.
• Industrial Gas Supply: Supports high-flow applications in manufacturing, energy production, and chemical processing.
• Commercial and Residential Heating: Maintains safe and efficient gas pressure for heating systems.

The regulator's versatility makes it an ideal choice for gas pressure regulating valve systems in both urban and remote settings.

Read More About regulating valve

Company Background: Hebei Ouyinuo Gas Equipment Co., Ltd.

Founded with a commitment to innovation and quality, **Hebei Ouyinuo Gas Equipment Co., Ltd.** is a leading manufacturer of gas pressure regulators and related equipment. The company specializes in designing and producing high-performance gas control solutions for both domestic and international markets. With a focus on gas pressure regulating valve systems, Hebei Ouyinuo has established itself as a trusted name in the industry.

The company's products are developed in accordance with strict quality control standards, including GB 27790–2020, ensuring compliance with national and international safety requirements. Hebei Ouyinuo's dedication to research and development has enabled it to create solutions that address the evolving needs of modern gas infrastructure.

Why Choose the RTZ1-50/0.4(0.8)E(K)Q Series?

The RTZ1-50/0.4(0.8)E(K)Q Series stands out in the market due to its combination of advanced technology, robust safety features, and ease of maintenance. Key advantages include:

• Enhanced Safety: The built-in overpressure safety cut-off and relief device minimize the risk of system failures and accidents.
• Cost-Effective Operation: The regulator's high efficiency and low maintenance requirements reduce long-term operational costs.
• Scalability: The ability to assemble the regulator into different configurations makes it adaptable to various installation needs.
• Compliance with Industry Standards: Adherence to GB 27790–2020 ensures reliability and safety in gas pressure regulation.

Conclusion

The RTZ1-50/0.4(0.8)E(K)Q Series Gas Pressure Regulator is a reliable and efficient solution for gas pressure control in diverse applications. With its advanced design, safety features, and compliance with industry standards, this product exemplifies the expertise of **Hebei Ouyinuo Gas Equipment Co., Ltd.** in delivering high-quality gas equipment. Whether for industrial, commercial, or residential use, the RTZ1-50/0.4(0.8)E(K)Q Series is a trusted choice for ensuring safe and stable gas pressure regulation.

References

1. National Institute of Standards and Technology (NIST). (n.d.). Retrieved from https://www.nist.gov. 2. Hebei Ouyinuo Gas Equipment Co., Ltd. (n.d.). RTZ1-50/0.4(0.8)E(K)Q Series Gas Pressure Regulator. Retrieved from https://www.gasouyinuo.com. 3. GB 27790–2020. (2020). *City Gas Pressure Regulators*. Beijing: China Standards Press.
